eDingo® 500 Electric Mini Skid Steer Toro Equipment
| Battery Capacity |
13.57 kW |
| Battery Charging Requirements |
15 amps at 120V |
| Battery Chemistry |
Toro HyperCell Lithium Ion |
| Dump Angle |
38 deg |
| Dump Height |
61 in. / 154.9 cm |
| Fuel Type |
Electric |
| Ground Clearance |
4.25 in. / 10.8 cm |
| Ground Speed – Forward |
Up to 2.75 mph / 4.43 km/h |
| Ground Speed – Reverse |
Up to 2.75 mph / 4.43 km/h |
| Height |
54.25 in. 137.8 cm |
| Height – With Bucket |
54.25 in. 137.8 cm |
| Hinge Pin Height |
81 in. / 205.7 cm |
| Hydraulic Flow – Traction |
6.5 GPM (24.6 LPM) |
| Hydraulic Pressure |
3,250 PSI |
| Length |
66.25 in. / 168.2 cm |
| Length – With Bucket |
88 in. / 223.5 cm |
| Loader Arms |
Radial |
| Max Operating Height |
106 in. / 269.2 cm |
| Rated Operating Capacity* |
515 lbs / 233.6 kg |
| Reach – Fully Raised |
21.5 in. / 54.6 cm |
| Reservoir Capacity |
6 gal. / 22.7 L |
| Standard Wheels |
Non-marking |
| Tip Capacity |
1,251 lbs / 567 kg |
| Weight |
2,342 lbs / 1,062 kg |
| Wheelbase |
28 in. / 71.1 cm |
| Width |
30 in. / 76.2 cm |
| Width – With Bucket |
41.8 in. / 106.2 cm |
