Snorkel A46JRT Snorkel

  Back to Inventory

Max. working height
52 ft 11 in
Max. platform height
46 ft 11 in
Max. horizontal reach
24 ft 11 in
Clearance height at max. outreach
25 ft 2 in
Platform size
39 in x 72 in
Chassis width
6 ft 10 in
Overall length
18 ft 8 in
Stowed height
7 ft 2 in
Ground clearance
13 in
Platform capacity (SWL)
500 lbs
Max. drive height
46 ft 11 in
Max. wind speed
28 mph
Max. drive speed (elevated)
0.8 mph
Max. drive speed (stowed)
4.25 mph
Raise / lower time
101 / 98 seconds
Gradeability
45%
Jib length
5 ft
Jib arc
140°
Platform rotation
160°
Superstructure rotation
360° non-continuous
Tailswing
0 in
Inside turning radius
2 ft 8 in
Outside turning radius
10 ft 5 in
Tires
Foam filled lug 355/55D625
Controls
Proportional
Drive system
4 wheel drive
Power source
Kubota V1505 24.9hp diesel – Tier 4 Final
Weight
16,620 lbs

  • Snorkel Guard™ secondary guarding system
  • Multi-function proportional controls
  • Oscillating front axle
  • Tri-entry platform
  • Foam filled lug tires
  • Power line to platform
  • Hour meter & on-board diagnostics display
  • Tilt alarm
  • Horn
  • Drive motion alarm
  • Flashing amber light
  • Platform overload system
  • Foam filled tires
  • 2 year parts & labor, 5 year structural warranty
  • Special paint colors
  • AC generator 110V/240V 2kW
  • Airline to platform
  • Non-marking tire
  • Environmental hydraulic oil
  • 1.52m aluminum platform with swing gate
  • Aircraft package
  • Deluxe aircraft package
  • Cold weather package
  • Extreme cold weather package
  • Extreme environment package
  • Light package
  • Glazier package
  • Tool tray
  • Pipe rack
  • Utility package
  • Personal fall arrest system
  • Snorkel OnSite™ telematics

Snorkel A46JRT Working Envelope Imp

Details

The class-leading Snorkel A46JRT articulating boom lift delivers precise reach and powerful rough terrain performance. Its up-and-over capabilities provide exceptional maneuverability with an articulated jib as standard for extended reach. A tight turning radius and zero tailswing makes the A46JRT a flexible and versatile machine for hard-to-reach places.

Equipment Type
Articulating Booms / Aerial Lifts
